Honda outboard 175HP

Category

By sharing many components with the Honda Odyssey and Honda Pilot, the BF175 gains years of proven Honda engineering, precision manufacturing, and reliability.

Overview
The BF175 features a Large Displacement Engine with a powerful, compact 24-valve SOHC design. Lacking the bulk and weight of long intake runners and multi-camshafts, the narrow V6 design offers top performance and durability, based on Honda’s automotive engineering excellence. The High-Performance Gearcase is designed to get you going faster, all the while reducing hull porpoising and minimizing spray, thus increasing acceleration and top speed.
Engine
Type 4-stroke SOHC 60 ° V6 / 24-valves
Displacement 3,471cc
Bore & Stroke 89 x 93 mm (3.5 x 3.9 inches)
Full Throttle RPM Range 5,000-6,000 RPM
Rated Power 175 HP @ 5,500 RPM
Cooling System Water Cooled  (Thermostatically controlled)
Fuel Delivery Programmed Fuel Injection
Ignition System Micro Computer Programmed
Starting System Electric
Exhaust Through Hub
Lubrication Wet Sump
Trim Range -4° to +16°
Tilt Range 72°
Drive
Gear Ratio 1.87:1
Gear Shift F-N-R
Alternator 60 Amp Total
Propeller Optional
Power Tilt NA
Power Trim & Tilt 72°
Gas Assisted Tilt NA
Oil Pressure Alert Standard
Temperature Alert Standard
Rev-Limiter Standard
Speedometer Pickup Standard
Dimensions
Overall Length 920 mm/36 inches
Overal Width 625 mm/25 inches
Transom Height
L Type NA
X Type 635 mm/25 inches
Dry Weight
L Type NA
X Type  272 kg/600 lbs
