Honda Outboard BF115

Category
Overview
Take the joy of boating to the next level with the new BF115 We’ve reengineered and redesigned the 115, added the new BF140, and added upgrades and improvements that boost performance. Available in Aquamarine Silver or Grand Prix White, the BF115, all feature sleek, aerodynamic styling for a bold, new look. But good looks are just the beginning. All three outboards are now available with Honda’s Intelligent Shift and Throttle (iST®) drive-by-wire system, for superb control and power. Repositioned anodes and a new bolt coating boost corrosion resistance. The redesigned cowl provides easier spark plug access. Other redesigned and repositioned components include the trim and tilt unit, water separator, fuel filters, and an enlarged dipstick tube. Combined with enhanced diagnostic codes, these changes make maintenance easier than ever, and significantly reduce maintenance time. The redesigned, reengineered Honda BF115 deliver everything you want – and more.
Engine
Type 4-Stroke SOHC 4 Cylinder/16 Valves
Displacement 2354cc (144 cubic ins.)
Bore & Stroke 87 x 99 mm (3.43 x 3.9 ins.)
Full Throttle RPM Range 4500-6000RPM
Rated Power 115 HP @ 5250 RPM
Cooling System Water Cooled
Fuel Delivery Programmed Fuel Injection
Ignition System Micro Computer Programmed
Starting System Electric
Exhaust Through Hub
Lubrication Wet Sump
Trim Range -4° to +16°
Tilt Range 68°
Drive
Gear Ratio 2.14:1 (30/14)
Gear Shift F-N-R
Alternator (Electric Start) 55 Amps Total
Battery Charging Power 40 Amps
Propeller Optional
Power Tilt NA
Power Trim & Tilt Standard
Gas Assisted Tilt NA
Oil Pressure Alert Standard
Temperature Alert Standard
Rev-Limiter Standard
Speedometer Pickup Standard
Dimensions
Overall Width 610 mm/24 inches
Transom Height
L Type 508 mm/20 inches
X Type 635 mm/25 inches
Dry Weight
L Type 218 kg/480 lbs.(mech); 221kg/487lbs. (iST)
X Type 221 kg/487 lbs. (mech); 224kg/493 lbs. (iST)
